F-Series

Medium trucks to suit all applications

GVM: 10,000 – 30,000 kg
With nearly 40 models available in the overall F Series Range the Isuzu Medium Trucks Range is the largest on offer in New Zealand. With a model to suit every application you can’t afford to look anywhere else.

Overview

With an unequalled model range to choose from in the new Euro V F Series Range the decision to choose Isuzu should be an easy one to make. Over the years Isuzu has earned a well-deserved reputation, not just for outstanding reliability, but also for broad specification choice and low whole-of-life costs. Our new F Series trucks continue this tradition and build upon the qualities of their predecessors. The launch of the new Euro V F Series range has re-defined the next generation of trucks.

Download the F-Series brochure

FYH350 8X4

  • Isuzu 6-Rod and parabolic steel leaf spring rear suspension
  • Interaxle lock and cross locks on both axles as standard
  • Eaton Road Ranger 11 speed or Allison 4430 automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FYH350 Short Manual
30000
8 x 4
257 / 350 @ 2000
5080
Eaton RTO 11909 - 11S
MODEL
FYH350 Short Manual
GVM (kg)
30000
TYPE
8 x 4
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
5080
TRANSMISSION
Eaton RTO 11909 - 11S
FYH350 Manual
30000
8 x 4
257 / 350 @ 2000
5770
Eaton RTO 11909 - 11S
MODEL
FYH350 Manual
GVM (kg)
30000
TYPE
8 x 4
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
5770
TRANSMISSION
Eaton RTO 11909 - 11S
FYH350 Auto
30000
8 x 4
257 / 350 @ 2000
5770
Allison 4430 - 6A
MODEL
FYH350 Auto
GVM (kg)
30000
TYPE
8 x 4
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
5770
TRANSMISSION
Allison 4430 - 6A

FYJ350 8X4

  • Hendrickson HAS 461 air bag rear suspension
  • Taper leaf spring with Isuzu 6 rod and trunnion location system
  • Interaxle lock and cross locks on both axles as standard
  • Allison automatic 4430 transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FYJ350 Manual
30000
8 x 4
257 / 350 @ 2000
5770
Eaton RTO 11909 - 11S
MODEL
FYJ350 Manual
GVM (kg)
30000
TYPE
8 x 4
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
5770
TRANSMISSION
Eaton RTO 11909 - 11S
FYJ350 Auto
30000
8 x 4
257 / 350 @ 2000
5770
Allison 4430 - 6A
MODEL
FYJ350 Auto
GVM (kg)
30000
TYPE
8 x 4
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
5770
TRANSMISSION
Allison 4430 - 6A
FYJ350 Short Auto Concrete Spec
30000
8 x 4
257 / 350 @ 2000
5770
Allison 4430 - 6A
MODEL
FYJ350 Short Auto Concrete Spec
GVM (kg)
30000
TYPE
8 x 4
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
5770
TRANSMISSION
Allison 4430 - 6A

FXY350 and FXZ350 6X4

Air and Spring Suspension

  • Hendrickson HAS 461 air bag rear suspension
  • Interaxle lock and cross locks on both axles as standard
  • Eaton Road Ranger 11 speed or Allison automatic 4430 transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FXZ350 Auto
24000
6 x 4 TAPER LEAF SPRING WITH ISUZU 6 ROD & TRUNNION
257 / 350 @ 2000
4540
Allison 4430 - 6A
MODEL
FXZ350 Auto
GVM (kg)
24000
TYPE
6 x 4 TAPER LEAF SPRING WITH ISUZU 6 ROD & TRUNNION
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
4540
TRANSMISSION
Allison 4430 - 6A
FXY350 Auto
24000
6 x 4 HAS 400 AIR
257 / 350 @ 2000
4540
Allison 4430 - 6A
MODEL
FXY350 Auto
GVM (kg)
24000
TYPE
6 x 4 HAS 400 AIR
POWER (kW/hp@rpm)
257 / 350 @ 2000
WHEEL BASE (mm)
4540
TRANSMISSION
Allison 4430 - 6A

FRR500 4X2

  • Leaf spring rear suspension
  • Dual circuit air over hydraulic front and rear auto adjusting drum brakes
  • Manual or AMT transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FRR500
10700
4 x 2
151 / 205 @ 2600
4660
ISUZU MZW - 6P
MODEL
FRR500
GVM (kg)
10700
TYPE
4 x 2
POWER (kW/hp@rpm)
151 / 205 @ 2600
WHEEL BASE (mm)
4660
TRANSMISSION
ISUZU MZW - 6P
FRR500 AMT
10700
4 x 2
151 / 205 @ 2600
4660
ISUZU MZW-6P AMT
MODEL
FRR500 AMT
GVM (kg)
10700
TYPE
4 x 2
POWER (kW/hp@rpm)
151 / 205 @ 2600
WHEEL BASE (mm)
4660
TRANSMISSION
ISUZU MZW-6P AMT
FRR500 LWB
11000
4 x 2
177/ 240 @ 2400
4990
ISUZU MZW-6P
MODEL
FRR500 LWB
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
177/ 240 @ 2400
WHEEL BASE (mm)
4990
TRANSMISSION
ISUZU MZW-6P
FRR500 LWB AMT
11000
4 x 2
177/ 240 @ 2400
4990
ISUZU MZW-6P AMT
MODEL
FRR500 LWB AMT
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
177/ 240 @ 2400
WHEEL BASE (mm)
4990
TRANSMISSION
ISUZU MZW-6P AMT
FRR500 XL LWB
11000
4 x 2
177/ 240 @ 2400
5320
ISUZU MZW-6P
MODEL
FRR500 XL LWB
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
177/ 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
ISUZU MZW-6P
FRR500 XL LWB AMT
11000
4 x 2
177/ 240 @ 2400
5320
ISUZU MZW-6P AMT
MODEL
FRR500 XL LWB AMT
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
177/ 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
ISUZU MZW-6P AMT

FRD500 4X2

  • Hendrickson HAS200 air bag rear suspension
  • Dual circuit air over hydraulic front and rear auto adjusting drum brakes
  • Manual or AMT transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FRD500 SWB MT
10700
4 x 2
151 / 205 @ 2600
4660
ISUZU MZW-6P
MODEL
FRD500 SWB MT
GVM (kg)
10700
TYPE
4 x 2
POWER (kW/hp@rpm)
151 / 205 @ 2600
WHEEL BASE (mm)
4660
TRANSMISSION
ISUZU MZW-6P
FRD500 SWB AMT
10700
4 x 2
151 / 205 @ 2600
4660
ISUZU MZW-6P
MODEL
FRD500 SWB AMT
GVM (kg)
10700
TYPE
4 x 2
POWER (kW/hp@rpm)
151 / 205 @ 2600
WHEEL BASE (mm)
4660
TRANSMISSION
ISUZU MZW-6P
FRD500 XLWB AMT
11000
4 x 2
177/ 240 @ 2400
5320
9 Speed Manual
MODEL
FRD500 XLWB AMT
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
177/ 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
9 Speed Manual
FRD500 XLWB
11000
4 x 2
177/ 240 @ 2400
5320
9 Speed Manual
MODEL
FRD500 XLWB
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
177/ 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
9 Speed Manual

FRR500 TIPPER 4X2

  • Manual or AMT transmission
  • Up to 6.2 tonne payload
  • Factory fitted Automatic body lock
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FRR500 TIPPER
10700
4 x 2
151 / 205 @ 2600
3790
ISUZU MZW-6P
MODEL
FRR500 TIPPER
GVM (kg)
10700
TYPE
4 x 2
POWER (kW/hp@rpm)
151 / 205 @ 2600
WHEEL BASE (mm)
3790
TRANSMISSION
ISUZU MZW-6P
FRR500 TIPPER AMT
10700
4 x 2
151 / 205 @ 2600
3790
ISUZU 6S AMT
MODEL
FRR500 TIPPER AMT
GVM (kg)
10700
TYPE
4 x 2
POWER (kW/hp@rpm)
151 / 205 @ 2600
WHEEL BASE (mm)
3790
TRANSMISSION
ISUZU 6S AMT

FRR600 4X2

  • Leaf spring rear suspension
  • Dual circuit air-over-hydraulic front and rear brakes
  • Manual or Allison LCT2500 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FRR600M AUTO
11000
4 x 2
191 / 260 @ 2400
4360
Allison LCT2500
MODEL
FRR600M AUTO
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4360
TRANSMISSION
Allison LCT2500
FRR600L AUTO
11000
4 x 2
191 / 260 @ 2400
5160
Allison LCT2500
MODEL
FRR600L AUTO
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5160
TRANSMISSION
Allison LCT2500
FRR600
11000
4 x 2
191 / 260 @ 2400
5160
ISUZU MZW-6P
MODEL
FRR600
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5160
TRANSMISSION
ISUZU MZW-6P
FRR600 CREW AMT
11000
4 x 2
191 / 260 @ 2400
5160
Allison LCT2500
MODEL
FRR600 CREW AMT
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5160
TRANSMISSION
Allison LCT2500

FRD600L AUTO 4X2

  • Hendrickson HAS200 air bag rear suspension
  • Dual circuit air-over-hydraulic front and rear brakes
  • Allison LCT2500 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FRD600L AUTO
11000
4 x 2
191 / 260 @ 2400
5160
Allison LTC2500
MODEL
FRD600L AUTO
GVM (kg)
11000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5160
TRANSMISSION
Allison LTC2500

FSR700 4X2

  • Leaf spring rear suspension
  • Dual circuit air-over-hydraulic front and rear brakes
  • Manual or Allison LCT2500 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FSR700
14000
4 x 2
191 / 260 @ 2400
5560
ISUZU MZW-6P
MODEL
FSR700
GVM (kg)
14000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
ISUZU MZW-6P
FSR700M AUTO
14000
4 x 2
191 / 260 @ 2400
3790
Allison LTC2500
MODEL
FSR700M AUTO
GVM (kg)
14000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
3790
TRANSMISSION
Allison LTC2500
FSR700ML AUTO
14000
4 x 2
191 / 260 @ 2400
5560
Allison LTC2500
MODEL
FSR700ML AUTO
GVM (kg)
14000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
Allison LTC2500
FSR650
12000
4 x 2
191 / 260 @ 2400
5560
ISUZU MZW-6P
MODEL
FSR650
GVM (kg)
12000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
ISUZU MZW-6P
FSR650L AUTO
12000
4 x 2
191 / 260 @ 2400
5560
Allison LTC2500
MODEL
FSR650L AUTO
GVM (kg)
12000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
Allison LTC2500
FSR650 240 LWB
12000
4 x 2
177 / 240 @ 2400
5320
ISUZU MZW-6P
MODEL
FSR650 240 LWB
GVM (kg)
12000
TYPE
4 x 2
POWER (kW/hp@rpm)
177 / 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
ISUZU MZW-6P
FSR650 240 AMT LWB
12000
4 x 2
177 / 240 @ 2400
5320
ISUZU MZW-6P
MODEL
FSR650 240 AMT LWB
GVM (kg)
12000
TYPE
4 x 2
POWER (kW/hp@rpm)
177 / 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
ISUZU MZW-6P
FSR700 240 LWB
14000
4 x 2
177 / 240 @ 2400
5320
ISUZU MZW-6P
MODEL
FSR700 240 LWB
GVM (kg)
14000
TYPE
4 x 2
POWER (kW/hp@rpm)
177 / 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
ISUZU MZW-6P
FSR700 240 AMT LWB
16000
4 x 2
177/ 240 @ 2400
5320
ISUZU MZW-6P
MODEL
FSR700 240 AMT LWB
GVM (kg)
16000
TYPE
4 x 2
POWER (kW/hp@rpm)
177/ 240 @ 2400
WHEEL BASE (mm)
5320
TRANSMISSION
ISUZU MZW-6P

FSD700 4X2

  • Hendrickson HAS200 air bag rear suspension
  • Dual circuit air-over-hydraulic front and rear brakes
  • Manual or Allison LCT2500 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FSD700
14000
4 x 2
191 / 260 @ 2400
5560
ISUZU MZW - 6P
MODEL
FSD700
GVM (kg)
14000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
ISUZU MZW - 6P
FSD700 AUTO
14000
4 x 2
191 / 260 @ 2400
5560
Allison LTC2500
MODEL
FSD700 AUTO
GVM (kg)
14000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
Allison LTC2500
FSD650
12000
4 x 2
191 / 260 @ 2400
5560
ISUZU MZW - 6P
MODEL
FSD650
GVM (kg)
12000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
ISUZU MZW - 6P
FSD650 AUTO
12000
4 x 2
191 / 260 @ 2400
5560
Allison LTC2500
MODEL
FSD650 AUTO
GVM (kg)
12000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5560
TRANSMISSION
Allison LTC2500

FSS550P 4X4

  • Leaf spring rear suspension
  • Factory fitted engine driven PTO
  • Part time 4WD
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FSS550 PTO
11000
4 x 4
154/ 210 @ 1600
3700
ISUZU MZW-6P 6S
MODEL
FSS550 PTO
GVM (kg)
11000
TYPE
4 x 4
POWER (kW/hp@rpm)
154/ 210 @ 1600
WHEEL BASE (mm)
3700
TRANSMISSION
ISUZU MZW-6P 6S
FSS550 CREW
11000
4 x 4
154/ 210 @ 1600
4200
ISUZU MZW-6P 6S
MODEL
FSS550 CREW
GVM (kg)
11000
TYPE
4 x 4
POWER (kW/hp@rpm)
154/ 210 @ 1600
WHEEL BASE (mm)
4200
TRANSMISSION
ISUZU MZW-6P 6S
FSS550 CREW PTO
11000
4 x 4
154/ 210 @ 1600
4200
ISUZU MZW-6P 6S
MODEL
FSS550 CREW PTO
GVM (kg)
11000
TYPE
4 x 4
POWER (kW/hp@rpm)
154/ 210 @ 1600
WHEEL BASE (mm)
4200
TRANSMISSION
ISUZU MZW-6P 6S

FTR750 4X2

  • Leaf spring rear suspension
  • Dual circuit, full air brakes
  • Manual or Allison LCT2500 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FTR750M
15000
4 x 2
191 / 260 @ 2400
4250
ISUZU MZW - 6P
MODEL
FTR750M
GVM (kg)
15000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
ISUZU MZW - 6P
FTR750M Auto
15000
4 x 2
191 / 260 @ 2400
4250
Allison LTC2500
MODEL
FTR750M Auto
GVM (kg)
15000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
Allison LTC2500
FTR750L
15000
4 x 2
191 / 260 @ 2400
5500
ISUZU MZW - 6P
MODEL
FTR750L
GVM (kg)
15000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5500
TRANSMISSION
ISUZU MZW - 6P
FTR750L AUTO
15000
4 x 2
191 / 260 @ 2400
5500
Allison LTC2500
MODEL
FTR750L AUTO
GVM (kg)
15000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
5500
TRANSMISSION
Allison LTC2500
FTR750L TIPPER
15000
4 x 2
191 / 260 @ 2400
4250
ISUZU MZW-6P
MODEL
FTR750L TIPPER
GVM (kg)
15000
TYPE
4 x 2
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
ISUZU MZW-6P

FTS800 4X4

  • Leaf spring rear suspension
  • Crew cab option
  • Isuzu TF56 Full time 4WD with driver activated centre diff lock
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FTS800
13900
4 x 4
191 / 260 @ 2400
4250
ISUZU MZW - 6P
MODEL
FTS800
GVM (kg)
13900
TYPE
4 x 4
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
ISUZU MZW - 6P
FTS800 PTO
13900
4 x 4
191 / 260 @ 2400
4250
ISUZU MZW - 6P
MODEL
FTS800 PTO
GVM (kg)
13900
TYPE
4 x 4
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
ISUZU MZW - 6P
FTS800 CREW
13900
4 x 4
191 / 260 @ 2400
4250
ISUZU MZW - 6P
MODEL
FTS800 CREW
GVM (kg)
13900
TYPE
4 x 4
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
ISUZU MZW - 6P
FTS800 AUTO
13900
4 x 4
191 / 260 @ 2400
4250
Allison LTC2500
MODEL
FTS800 AUTO
GVM (kg)
13900
TYPE
4 x 4
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
Allison LTC2500
FTS800 CREW AUTO
13900
4 x 4
191 / 260 @ 2400
4250
ISUZU MZW - 6P
MODEL
FTS800 CREW AUTO
GVM (kg)
13900
TYPE
4 x 4
POWER (kW/hp@rpm)
191 / 260 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
ISUZU MZW - 6P

FVR1000M 4X2

  • Leaf spring rear suspension
  • Meritor Q-Plus dual circuit, full air, S-cam drum brakes with auto-adjusting slack adjusters
  • 9 Speed ZF manual
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FVR1000M
16500
4 x 2
221 / 300 @ 2400
4250
9 Speed Manual
MODEL
FVR1000M
GVM (kg)
16500
TYPE
4 x 2
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
9 Speed Manual
FVR950M
16500
4 x 2
221 / 300 @ 2400
4250
9 Speed Manual
MODEL
FVR950M
GVM (kg)
16500
TYPE
4 x 2
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
4250
TRANSMISSION
9 Speed Manual

FVD1000A 4X2

  • Hendrickson HAS230 air bag suspension
  • Meritor Q-Plus dual circuit, full air, S-cam drum brakes with auto-adjusting slack adjusters
  • Allison 3000 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FVD950 AUTO
16500
4 x 2
221 / 300 @ 2400
5520
Allison 3000-6A
MODEL
FVD950 AUTO
GVM (kg)
16500
TYPE
4 x 2
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
5520
TRANSMISSION
Allison 3000-6A
FVD1000A
16500
4 x 2
221 / 300 @ 2400
5550
Allison MD 3000-6A
MODEL
FVD1000A
GVM (kg)
16500
TYPE
4 x 2
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
5550
TRANSMISSION
Allison MD 3000-6A

FVY1400 6X4

  • Hendrickson HAS 460 air bag suspension
  • Meritor Q-Plus dual circuit, full air, S-cam drum brakes with auto-adjusting slack adjusters
  • 9 Speed ZF manual or Allison 3000 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FVY1350A
18000
6 x 4
221 / 300 @ 2400
6470
Allison MD3560P
MODEL
FVY1350A
GVM (kg)
18000
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
6470
TRANSMISSION
Allison MD3560P
FVY1350L
18000
6 x 4
221 / 300 @ 2400
6470
9 Speed Manual
MODEL
FVY1350L
GVM (kg)
18000
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
6470
TRANSMISSION
9 Speed Manual
FVY1400 AUTO
24000
6 x 4
221 / 300 @ 2400
6470
Allison 3000-6A
MODEL
FVY1400 AUTO
GVM (kg)
24000
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
6470
TRANSMISSION
Allison 3000-6A
FVY1400L
2400
6 x 4
221 / 300 @ 2400
6470
9 Speed Manual
MODEL
FVY1400L
GVM (kg)
2400
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
6470
TRANSMISSION
9 Speed Manual

FVL1400 6X2

  • Hendrickson HAS 460 air bag suspension
  • Meritor Q-Plus dual circuit, full air, S-cam drum brakes with auto-adjusting slack adjusters
  • 9 Speed ZF manual
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FVL1400
24000
6 x 2
221 / 300 @ 2400
6470
9 Speed Manual
MODEL
FVL1400
GVM (kg)
24000
TYPE
6 x 2
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
6470
TRANSMISSION
9 Speed Manual
FVL1400
18000
6 x 2
221 / 300 @ 2400
6470
9 Speed Manual
MODEL
FVL1400
GVM (kg)
18000
TYPE
6 x 2
POWER (kW/hp@rpm)
221 / 300 @ 2400
WHEEL BASE (mm)
6470
TRANSMISSION
9 Speed Manual

FVZ1400 6X4

  • Multi leaf with 6 rod and trunion location rear suspension
  • Meritor Q-Plus dual circuit, full air, S-cam drum brakes with auto-adjusting slack adjusters
  • 9 Speed ZF manual or Allison 3000 Automatic transmission
  • Isringhausen air suspended seat

MODEL

GVM (kg)

TYPE

POWER (kW/hp@rpm)

WHEEL BASE (mm)

TRANSMISSION

FVZ1400M
24000
6 x 4
221 / 300 @ 24000
4410
9 Speed Manual
MODEL
FVZ1400M
GVM (kg)
24000
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 24000
WHEEL BASE (mm)
4410
TRANSMISSION
9 Speed Manual
FVZ1400 AUTO
24000
6 x 4
221 / 300 @ 24000
5300
Allison MD 3060P
MODEL
FVZ1400 AUTO
GVM (kg)
24000
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 24000
WHEEL BASE (mm)
5300
TRANSMISSION
Allison MD 3060P
FVZ1350M
18000
6 x 4
221 / 300 @ 24000
4410
9 Speed Manual
MODEL
FVZ1350M
GVM (kg)
18000
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 24000
WHEEL BASE (mm)
4410
TRANSMISSION
9 Speed Manual
FVZ1350 AUTO
18000
6 x 4
221 / 300 @ 24000
5300
Allison MD 3060P
MODEL
FVZ1350 AUTO
GVM (kg)
18000
TYPE
6 x 4
POWER (kW/hp@rpm)
221 / 300 @ 24000
WHEEL BASE (mm)
5300
TRANSMISSION
Allison MD 3060P

Please note: Information subject to change without notice.
Vehicle ratings and front / rear mass limits are subject to regulatory requirements – Consult your dealer to select a specific vehicle to suit your requirements.
